Apraksts

• Specification
• Relay type electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 24V DC
• Contact current max. 30A
• Relay series L90
• Relay variant sealed, power
• Mounting PCB
• Operating temperature -55...85°C
• Leads for PCB
• Coil resistance 660Ω;
• Switched voltage max 240V AC, max 30V DC
• Coil power consumption 900mW
• Contact resistance 50mΩ;
• DC contacts rating
• (at resistance load) 20 A / 30 VDC
• Operate time 15ms
• Release time 15ms
• AC contacts rating
• (at resistance load) 30 A / 240 VAC
• Mechanical durability 10000000cycles
• Contact material AgCdO
• Electrical life 100000cycles

Parametri

RAYEX ELECTRONICS
DC24V
SPDT
30A/240VAC
20A/30VDC
uz pārslēgšanu
monostabilais
1
