Apraksts

• Manufacturer RAYEX ELECTRONIC
• Relay type electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 24V DC
• Contact current max. 80A
• DC contacts rating
• (at resistance load) 60 A / 14 VDC
• Relay variant automotive
• Coil resistance 288Ω
• Contact material AgCdO
• Operating temperature -40...85°C
• Relay series AM3
• Body dimensions 28 x 28 x 25mm
• Mounting on panel
• Coil power consumption 1.8W
• Contact resistance 50mΩ
• Coil current 83mA
• Leads 6.3x0.8mm connectors, 9.5x1.2mm connectors
• Operate time 7ms
• Release time 5ms

Parametri

RAYEX ELECTRONICS
DC24V
SPDT
uz pārslēgšanu
monostabilais
1
60A/14VDC

Papildu dokumentācija
