Apraksts

• Manufacturer OMRON Electronic Components
• Type of relay electromagnetic
• Contacts configuration DPDT
• Contacts configuration
• Rated coil voltage 48V DC
• Contact current max. 8A
• AC contacts rating @R(at resistive load) 8A / 250V AC
• at resistive load
• DC contacts rating @R(at resistive load) 8A / 24V DC
• at resistive load
• Manufacturer series G2RL
• Switched voltage max. 300V DC, max. 440V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 5358Ω
• Operate time 15ms
• Body dimensions 29x12,7x15,7mm
• Release time 5ms
• Operating temperature -40...85°C
• Contact resistance 100mΩ
• Terminal pitch 5mm
• Coil current 8,96mA
• Leads for PCB
• Enclosure description standard seal
• Masa bruto11.68 g

Parametri

OMRON
DC48V
DPDT
8A/250VAC
8A/24VDC
uz pārslēgšanu
monostabilais
2
