Apraksts

• Manufacturer TE Connectivity
• Type of relay electromagnetic
• Contacts configuration SPST-NO
• Rated coil voltage 48V DC
• AC contacts rating @R
• (at resistance load) 6A / 250V AC
• DC contacts rating @R
• (at resistance load) 6A / 30V DC
• Contact current max. 6A
• Switched voltage max 300V DC, max 400V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 11.52kΩ
• Coil voltage min. 33.6V DC
• Operate time 10ms
• Body dimensions 20 x 10.6 x 10mm
• Release time 5ms
• Coil power consumption 200mW
• IP rating IP67
• Mechanical durability 300000000cycles
• Operating temperature -40...70°C
• Weight 5g
• Relay series RE
• Contact material AgCdO
• Terminal pitch 7.62mm
• Coil current 4.2mA

Parametri

TE Connectivity
DC48V
SPST-NO
6A/250VAC
6A/30VDC
uz saslēgšanu
monostabilais
1

Papildu dokumentācija
