Apraksts

• Manufacturer E-SWITCH
• Type of switch slide
• Number of positions 3
• DC contacts rating @R(at resistive load) 0,2A / 30V DC
• at resistive load
• Switching method(the position in bracket indicates momentary position.) ON-ON-ON
• The position in bracket indicates momentary position.
• Mounting THT
• Leads angled, for PCB
• Operating temperature -20...70°C
• Body dimensions 12,6x6,8x4,7mm
• Manufacturer series EG
• Contact plating silver plated
• Contact material copper
• Knob height 3,5mm
• Mechanical durability 10000 cykli
• Stable positions number 3
• Masa bruto0.92 g

Parametri

DP3T
0.2A/30VDC
2
ON-ON-ON
3

Papildu dokumentācija
