Apraksts

• Specification
• Switch type slide
• Stable positions number 2-position
• Contacts configuration SPDT
• AC contacts rating
• (at resistance load) 3 A / 250 VAC
• DC contacts rating
• (at resistance load) 6 A / 28 VDC
• Switching method ON-ON
• Leads straight
• Min. insulation resistance 100MΩ;
• Operating temperature -20...85°C
• Mechanical durability 30000cycles
• Max. contact resistance: 10mΩ;
• Mounting THT
• Body dimensions 12.8 x 6.7 x 6.35mm
• Contact plating silver plated
• Contact material copper
• Actuator material polyamide
• Terminal pitch 4.7mm
• Body material stainless steel
• Terminals material copper alloy
• Terminals plating silver plated

Parametri

SPDT
3A/250VAC
6A/28VDC
1
ON-ON
2
