Apraksts

• Manufacturer NINIGI
• Type of connector PCB terminal block
• Spatial orientation  angled 90°
• Contacts pitch 3.5mm
• Number of ways 2
• Mechanical mounting on PCBs
• Electrical mounting THT,  screw terminal
• Connector terminal
• Contact plating tinned
• Current rating 12A
• Height 9.1mm
• Colour blue
• Rated voltage  300V
• Body material PBT
• Connectors features assembling possibility
• Length 7mm
• Contact material brass
• Operating temperature -40...105°C
• Depth 7.4mm
• Flammability rating UL94V-0
• Type of pin configuration 1x2
• Wire cross section 1mm2
• Additional information
• Gross weight: 1.04 g
• Manufacturer part number: TB-3.5-P-2P-BL

Parametri

2
3.5mm
Aizspiednis kontakts PCB
Leņķisks 90°
Terminal blocks PCB

Papildu dokumentācija
