Apraksts

• Manufacturer DEGSON ELECTRONICS
• Type of connector pluggable terminal block
• Contacts pitch 5.08mm
• Number of ways 3
• Spatial orientation straight
• Information about relative position of each cable, terminals or PCB entry
• Connector plug
• Kind of connector male
• Mechanical mounting for cable
• Electrical mounting cage clamp, screw terminal
• Wire cross-section 2.5mm2
• Wire size 28AWG...12AWG
• Flammability rating UL94V-0
• ECE R-118:
• Body material polyamide 66
• Colour green
• Operating temperature -40...105°C
• Rated voltage 320V
• Locking system latch
• Current rating 20A
• Contact material copper
• Connector pinout layout 1x3
• Conform to the norm CE UL
• Number of terminals 4
• Gross weight3.283 g

Parametri

5.08mm
3
Spraudnis
Taisns
Uz vadu

Papildu dokumentācija
