Apraksts

• Manufacturer: Texas Instruments
• Product Category: Audio Amplifiers
• RoHS: Details
• Series: TAS5142
• Product: Audio Amplifiers
• Class: Class-AB
• Output Power: 100 W
• Mounting Style: SMD/SMT
• Type: 1-Channel Mono or 2-Channel Stereo or 4-Channel Stereo
• Package/Case: HSSOP-36
• Audio - Load Impedance: 2 Ohms
• THD plus Noise: 0.1 %
• Minimum Operating Temperature: 0 C
• Maximum Operating Temperature: + 70 C
• Packaging: Tube
• Description/Function: Speaker
• Height: 3.3 mm
• Input Type: Single
• Length: 14.5 mm
• Output Type: 1-Channel Mono, 2-Channel Stereo, 4-Channel Stereo
• Supply Type: Triple
• Width: 16 mm
• Brand: Texas Instruments
• Number of Channels: 4 Channel
• Supply Current - Max: 17 mA, 16 mA, 25 mA
• Dual Supply Voltage: 12 V, 32 V
• Maximum Dual Supply Voltage: 13.2 V, 13.2 V, 34 V
• Minimum Dual Supply Voltage: 0 V, 10.8 V
• Moisture Sensitive: Yes
• Operating Supply Current: 7 mA, 5 mA, 15 mA
• Output Signal Type: Differential
• Product Type: Audio Amplifiers
