Apraksts

• Manufacturer: NXP
• Product Category: Audio Amplifiers
• Product: Audio Amplifiers
• Class: Class-AB
• Output Power: 24 W
• Mounting Style: Through Hole
• Type: 1-Channel Mono or 2-Channel Stereo or 4-Channel Stereo
• Package/Case: DBSP
• Audio - Load Impedance: 8 Ohms
• THD plus Noise: 0.05 %
• Supply Voltage - Max: 26 V
• Supply Voltage - Min: 9 V
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 85 C
• Brand: NXP Semiconductors
• Description/Function: Speaker
• Gain: 26 dB
• Height: 12.2 mm
• Ib - Input Bias Current: 4000 mA
• Input Type: Single
• Length: 24 mm
• Number of Channels: 4 Channel
• Operating Supply Current: 100 mA
• Operating Supply Voltage: 17 V
• Output Current: 4000 mA
• Output Signal Type: Differential, Single
• Output Type: 1-Channel Mono, 2-Channel Stereo, 4-Channel Stereo
• Pd - Power Dissipation: 69 W
• Product Type: Audio Amplifiers
• Subcategory: Audio ICs
• Supply Type: Single
• Width: 4.6 mm
• Part # Aliases: TDA8948J
• Unit Weight: 4,769 g
