Apraksts

• Manufacturer E-SWITCH
• Type of switch microswitch TACT
• Contacts configuration  SPST-NO
• Number of positions 2
• DC contacts rating @R  0.05A / 12V DC
• Mounting THT
• Operating Force 1.57N
• Body dimensions 6x6x4mm
• Button height  17mm
• Switching method  OFF-(ON)
• Terminal pitch 6.5x4.5mm
• Operating temperature -40...85°C
• Button shape round
• Actuator colour black
• Key stroke 0.25mm
• Leads for PCB
• Max. contact resistance: 100mΩ
• Mechanical durability 100000 cycles
• Stable positions number 1
• Papildu informācijas
• Masa bruto: 0.335 g
• Oriģināls simbols: TL1105LF160Q

Parametri

THT
SPST-NO
0.05A/12VDC
6x6x4mm
1.6N
13mm
Horizontāli
