• Manufacturer OMRON OCB
• Type of switch microswitch TACT
• Contacts configuration  SPST-NO
• Number of positions 2
• DC contacts rating @R  0.05A / 24V DC
• Mounting THT
• Illumination none
• Operating Force 1.47N
• Body dimensions 6x6mm
• Button height  7.3mm
• Switching method  OFF-(ON)
• Terminal pitch 4.5x6.5mm
• Operating temperature -25...70°C
• Button shape square
• Actuator colour yellow
• Key stroke 0.25mm
• Leads for PCB,  straight
• Contact material phosphor bronze
• Max. contact resistance: 100mΩ
• Min. insulation resistance 100MΩ
• Manufacturer series B3F
• Contact plating silver plated
• Mechanical durability 300000 cycles
• Related items B32-1000,  B32-1010,  B32-1030,  B32-1060,  B32-1080
• Switches features with ground terminal
• Stable positions number 1
• Additional information
• Gross weight: 0.296 g
• Manufacturer part number: B3F-1152

Parametri

THT
SPST-NO
0.05A/24VDC
6x6x4mm
1.47N
3.5mm
Horizontāli

Papildu dokumentācija
