Apraksts

• Manufacturer OMRON OCB
• Type of switch microswitch TACT
• Contacts configuration SPST-NO
• Number of positions 2
• DC contacts rating @R
• (at resistive load) 0.05A / 24V DC
• Mounting THT
• Illumination none
• Operating Force 1.96N
• Body dimensions 12x12mm
• Button height
• (measured from PCB) 7.3mm
• Switching method
• (item in brackets is instantaneous) OFF-(ON)
• Operating temperature -25...70°C
• Button shape square
• Actuator colour white
• Leads for PCB, straight
• Max. contact resistance: 100mΩ
• Min. insulation resistance 100MΩ
• Manufacturer series B3W
• Contact plating silver plated
• IP rating IP67
• Mechanical durability 3000000 cycles
• Kind of package bulk
• Stable positions number 1 Additional information
• Gross weight: 0.936 g
• Manufacturer part number: B3W4050S

Parametri

THT
SPST-NO
0.05A/24VDC
IP67
12x12x4.3mm
1.96N
3.5mm
Horizontāli

Papildu dokumentācija
