Apraksts

• Manufacturer OMRON
• Type of switch microswitch TACT
• Contacts configuration SPST-NO
• Number of positions 2
• Stable positions number 1-position
• DC contacts rating @R
• (at resistance load) 0.05A / 24VDC
• Mounting THT
• Illumination none
• Operating Force 1.27N
• Body dimensions 12x12mm
• Button height
• (measured from PCB) 4.3mm
• Switching method
• (item in brackets is instantaneous) OFF-(ON)
• Button shape round
• Terminal pitch 5x12.5mm
• Operating temperature -25...70°C
• Actuator colour blue
• Leads for PCB, straight
• Max. contact resistance: 100mΩ
• Min. insulation resistance 100MΩ
• Manufacturer series B3F
• Mechanical durability 10000000cycles
• Contact plating silver plated
• Contact material phosphor bronze
• Key stroke 0.3mm

Parametri

THT
SPST-NO
0.05A/24VDC
12x12x4mm
1.27N
0.5mm
Horizontāli

Papildu dokumentācija
