Apraksts

• Manufacturer NINIGI
• Type of switch microswitch TACT
• Contacts configuration SPST-NO
• Number of positions 2
• DC contacts rating @R
• (at resistive load) 0.05A / 12V DC
• Mounting SMT
• Illumination none
• Operating Force 1.8N
• Body material stainless steel, thermoplastic
• Body dimensions 4.5x6.1mm
• Button height
• (measured from PCB) 1.3mm
• Switching method
• (item in brackets is instantaneous) OFF-(ON)
• Terminal pitch 3.4x5.8mm
• Operating temperature -20...70°C
• Button shape rectangular
• Actuator colour blue
• Terminals material brass
• Terminals plating silver plated
• Leads for PCB
• Contact material phosphor bronze
• Max. contact resistance: 100mΩ
• Contact plating silver plated
• Electrical life 50000 cycles
• Stable positions number 1 Additional information
• Gross weight: 0.094 g

Parametri

SMD
SPST-NO
0.05A/12VDC
4.5x6.1mm
1.8N
1.3mm
Leņķisks 90°
