Apraksts

• Manufacturer OMRON OCB
• Type of switch microswitch TACT
• Contacts configuration  SPST-NO
• Number of positions 2
• DC contacts rating @R  0.05A / 12V DC
• Mounting SMT
• Operating Force 0.49N
• Body dimensions 2.5x3mm
• Button height  1.2mm
• Switching method  OFF-(ON)
• Terminal pitch 1.7x4.2mm
• Operating temperature -25...70°C
• Button shape rectangular
• Actuator colour black
• Key stroke 0.2mm
• Leads for PCB
• Max. contact resistance: 100mΩ
• Min. insulation resistance 100MΩ
• Manufacturer series B3U
• Mechanical durability 100000 cycles
• Stable positions number 1
• Additional information
• Gross weight: 0.082 g
• Manufacturer part number: B3U-3000PM-B

Parametri

SMD
SPST-NO
0.05A/24VDC
3x2.5x1.2mm
0.49N
0.7mm
Leņķisks 90°
