Apraksts

• Manufacturer SCI
• Type of switch ROCKER
• Contacts configuration SPST
• Number of positions 2
• Switching method(the position in bracket indicates momentary position.) ON-OFF
• AC contacts rating @R(at resistive load) 10A / 250V AC
• Key button colour red
• Illumination neon lamp
• Backlight colour red
• Illumination voltage 230V
• Max. contact resistance: 50mΩ
• Body colour black
• Body material polyamide
• Flammability rating UL94V-2
• Operating temperature -20...85°C
• Leads 4,8x0,8mm connectors
• Panel thickness max. 3mm
• Electrical life 6000 cycles
• Mounting hole diameter Ø20.2mm
• Button marking O-I
• Shape round
• Related items R13-112-12
• Manufacturer series R13-112-AC
• Stable positions number 2

Parametri

SPST
6A/250VAC
20A/12VDC
OFF-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
1
230VAC
