Apraksts

• Manufacturer SCI
• Type of switch ROCKER
• Contacts configuration  SP3T
• Number of positions 3
• Switching method  ON-OFF-ON
• AC contacts rating @R  10A / 250V AC
• Key button colour green-red
• IP rating IP66
• Illumination LED
• Max. contact resistance: 50mΩ
• Body colour black
• Flammability rating UL94V-2
• Operating temperature -20...85°C
• Leads 6,3x0,8mm connectors
• Panel thickness max. 3mm
• Mounting hole diameter 36.6x21.2mm
• Button marking blank
• Backlight colour red/green
• Shape rectangular
• Manufacturer series R13-292-AC
• Body dimensions 47.3x25x26.9mm
• Stable positions number 3
• Dimensions see
• Additional information
• Gross weight: 22.2 g
• Manufacturer part number: R13-292D3-0-1BBGR-22GR0300-5

Parametri

SP3T
10A/250VAC
ON-OFF-ON
3
IP66
3
Taustiņslēdzis
Ar fiksāciju
1
Bez apgaismojuma

Papildu dokumentācija
