Apraksts

• Manufacturer Marquardt
• Type of switch ROCKER
• Contacts configuration  DPST
• Number of positions 2
• Switching method  OFF-ON
• AC contacts rating @R  20A / 250V AC
• AC contacts rating @L  4A / 250V AC
• Key button colour orange
• IP rating IP40
• Illumination filament lamp 230V
• Max. contact resistance: 100mΩ
• Body colour black
• Flammability rating UL94V-2
• Operating temperature -20...85°C
• Leads 6,3x0,8mm connectors
• Panel thickness max. 3mm
• Mounting hole diameter 30.6x22mm
• Button marking I-O
• Backlight colour orange
• Shape rectangular
• Related items 203.201.011
• Manufacturer series 1835
• Button shape rectangular
• Dimensions 31.5x25x16.2mm
• Contact plating silver plated
• Stable positions number 2
• Additional information
• Gross weight: 11.74 g
• Manufacturer part number: 1835.3114

Parametri

DPST
20A/250VAC
OFF-ON
2
IP40
2
Taustiņslēdzis
Ar fiksāciju
2
230VAC

Papildu dokumentācija
