Apraksts

• Type of switch ROCKER
• Contacts configuration  DPST
• Number of positions 2
• Switching method  OFF-ON
• AC contacts rating @R  15A / 250V AC
• Key button colour green
• Illumination neon lamp
• Max. contact resistance: 35mΩ
• Body colour black
• Operating temperature -30...80°C
• Leads 6,3x0,8mm connectors
• Electrical life 10000 cycles
• Mounting hole diameter 31x22.3mm
• Button marking O-I
• Backlight colour green
• Related items RSC09
• Button shape rectangular
• Height above panel 9.4mm
• Stable positions number 2
• Additional information
• Gross weight: 15.858 g
• Manufacturer part number: RSI2013C3GN

Parametri

DPST
15A/250VAC
OFF-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
2
230VAC

Papildu dokumentācija
