Apraksts

• Specification
• Switch type ROCKER
• Contacts configuration SPDT
• AC contacts rating
• (at resistance load) 10 A / 250 VAC
• DC contacts rating
• (at resistance load) 16 A / 12 VDC
• Switching method ON-(ON)
• Actuator colour black
• Max. contact resistance: 50mΩ;
• Leads 4.8x0.8mm connectors
• Flammability rating UL94V-2
• Panel thickness max 3mm
• Electrical life 6000cycles
• Operating temperature -20...85°C
• Button marking --=
• Body material polyamide

Parametri

SPDT
10A/250VAC
16A/12VDC
ON-(ON)
2
IP00
1
Taustiņslēdzis
Bez fiksācijas
1
Bez apgaismojuma

Papildu dokumentācija
