Apraksts

• Specification
• Switch type ROCKER
• Switching method (ON)-OFF
• Contacts configuration SPST
• AC contacts rating 10 A / 250 V
• Actuator colour black
• Max. contact resistance: 50mΩ;
• Leads 6.3 x 0.8 mm connectors
• Flammability rating UL94V-2
• Panel thickness max 3mm
• Electrical life 6000cycles
• Button marking blank
• Mounting hole diameter 30.4 x 11.2mm
• Body material polyamide

Parametri

SPST
10A/250VAC
20A/12VDC
OFF-(ON)
2
IP00
1
Taustiņslēdzis
Bez fiksācijas
1
Bez apgaismojuma

Papildu dokumentācija
