Apraksts

• Manufacturer INDEL
• Type of transformer mains
• Power 4VA
• Primary voltage 230V AC
• Secondary voltage 1 18V
• Secondary voltage 2 18V
• Secondary winding current 1 0.12A
• Secondary winding current 2 0.12A
• Mounting screw type
• IP rating IP00
• Conform to the norm PN-EN 61558
• Thermal class Ta40B
• Secondary winding terminals 8-7, 5-6
• Primary winding terminals 1-4
• Insulation class I
• Electrical insulation strength 4kV/60s
• Leads for PCB
• Transformer jumper 3-2
• Additional information
• Gross weight: 163.6 g
• Manufacturer part number: TS4/026

Parametri

2x18VAC
2
2x120mA
4VA

Papildu dokumentācija
