Apraksts

• Manufacturer BREVE TUFVASSONS
• Type of transformer encapsulated
• Power 4VA
• Primary voltage 230V AC
• Secondary voltage 1 6V
• Secondary voltage 2 6V
• Secondary winding current 1 333,3mA
• Secondary winding current 2 333,3mA
• Mounting PCB
• IP rating IP00
• Conform to the norm PN EN 61558-1:2000 PN EN 61558-2-1:2000 PN EN 61558-2-6:2000
• Thermal class Ta60B
• Manufacturer series TEZ
• Secondary winding terminals 6-7, 9-10
• Primary winding terminals 1-5
• A dimension 35mm
• A1 dimension 25mm
• A2 dimension 20mm
• B dimension 42mm
• C dimension 29mm
• Electrical insulation strength 4kV/60s
• Masa bruto152.2 g

Parametri

2x6VAC
2
2x330mA
4VA

Papildu dokumentācija
