Apraksts

• Manufacturer APEM
• Switch type toggle
• Stable positions number 2-position
• Contacts configuration DPDT
• Switching method ON-ON
• AC contacts rating
• (at resistance load) 15 A / 250 VAC
• DC contacts rating
• (at resistance load) 15 A / 12 VDC
• Leads for soldering
• Mounting hole diameter Ø12.2mm
• Operating temperature -20...55°C
• Number of positions 2
• Toggle type round
• Knob height 17.5mm
• Electrical life 10000cycles
• Body dimensions 29.5 x 14 x 15mm
• Contact plating silver nickel alloy
• Min. insulation resistance 1000MΩ
• Associated items U851

Parametri

DPDT
15A/250VAC
ON-ON
2
IP00
2
Tumblers
Ar fiksāciju
M12
2
Bez apgaismojuma
15A/12VDC

Papildu dokumentācija
