Apraksts

• Manufacturer E-SWITCH
• Type of switch toggle
• Number of positions 2
• Stable positions number 2
• Contacts configuration DPDT
• Contacts configuration
• Switching method(the position in bracket indicates momentary position.) ON-ON
• The position in bracket indicates momentary position.
• AC contacts rating @R(at resistive load) 2A / 250V AC
• at resistive load
• DC contacts rating @R(at resistive load) 5A / 28V DC
• at resistive load
• Leads angled, for PCB
• Manufacturer series 100
• Operating temperature -30...85°C
• Max. contact resistance: 10mΩ
• Body dimensions 12,7x11,43x12,7mm
• Electrical life 40000 cykli
• Contact plating silver plated
• Min. insulation resistance 1GΩ
• Contact material copper
• Mounting THT
• Lever length 6,46mm
• Masa bruto5.54 g

Parametri

DPDT
2A/250VAC
5A/28VDC
ON-ON
2
IP00
2
Tumblers
Ar fiksāciju
Bez vītnes
2
Bez apgaismojuma
