Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju
Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju
Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju
Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju

* Produktu fotogrāfijas ir tikai noskatīšanai un var dažreiz atšķirties no priekšmeta reāla izskata. Bet galvenās īpašības ir vienādas.

Tumblers, SP3T, ON-OFF-ON, 20A/12VDC, konektori 6.3mm, M12, 33.2x19x19mm, ar fiksaciju

Cena: 2.60 €
00027606
R13-28D-01
18
  • Apraksts

    • Manufacturer SCI
    • Type of switch toggle
    • Number of positions 3
    • Contacts configuration SP3T
    • Switching method
    • (item in brackets is instantaneous) ON-OFF-ON
    • DC contacts rating @R
    • (at resistive load) 20A / 12V DC
    • Leads 6,3mm connectors
    • Terminals plating nickel
    • Operating temperature 0...55°C
    • Kind of toggle round
    • Mounting hole diameter Ø12.2mm
    • Knob height 18.4mm
    • Max. contact resistance: 50mΩ
    • Body dimensions 33.2x19x19mm
    • Actuator material metal
    • Manufacturer series R13-28
    • Related items R1710A
    • Panel thickness max. 6mm
    • Test voltage 1.5kV
    • Stable positions number 3
    • Additional information
    • Gross weight: 25.25 g
    • Manufacturer part number: R13-28D-01-HPH

    Parametri

    SP3T
    20A/12VDC
    ON-OFF-ON
    3
    IP00
    3
    Tumblers
    Ar fiksāciju
    M12
    1
    bez apgaismojuma
