Apraksts

• Technical Information
• Rated supply voltage : 100-240VAC
• Rated output voltage : 15/16/18/19/20/22/24 VDC
• Rated output current : 6000mA for 15/16/18/19/20VDC , 5000mA for 22/24VDC
• Rated output : 120VA(max)
• Max. ambient temperature : 25
• Protection class : Class II
• IP Code : 20
• Adapter type : Switching Mode
• Input method : Desktop
• Frequency : 50/60 Hz
• Output plug : 6MC (NG, NH, NAA, NAB, NE, NJ)
• Application : Notebook
• Product Dimension : 160.5x80x39.5mm

Parametri

Savienotāju komplekts
Darbvirsma
15-24VDC
5A
120W
