Apraksts

• Manufacturer KEYSTONE
• Connector plug
• Connector type USB B micro
• Mechanical mounting for cable
• Electrical mounting soldered
• Number of pins 5
• Spatial orientation straight
• Variant USB 2.0
• Contact plating nickel plated, gold flash
• Operating temperature -25...80°C
• Max. contact resistance: 15mΩ
• Flammability rating UL94V-0
• Rated current 1A
• Rated voltage 30V
• Contact material phosphor bronze
• Insulator material thermoplastic
• Mechanical durability 1500cycles

Parametri

MicroUSB-B
Spraudnis
2.0

Papildu dokumentācija
