Apraksts

• Manufacturer SUNON
• Type of fan DC
• Kind of fan axial
• Operating voltage 4.5...13.8V DC
• Fan dimensions 60x60x20mm
• Power consumption 1.44W
• Current rating 0.115A
• Fan efficiency 38.19m3/h
• Noise level 32.5dBA
• Kind of Bearing slide
• Rotational rate/speed 4700rpm
• Current and power consumption tolerance ±15%
• Min. insulation resistance 10MΩ
• Impeller material thermoplastic
• Enclosure material thermoplastic
• Insulation class A
• Leads leads x2
• Lead length 0.29m
• Operating temperature -10...70°C
• Flammability rating UL94V-0
• Fan motor brushless DC
• Static pressure 4.57mm H2O
• Wire size 26AWG
• Related items BUB-72H
• Supply voltage
• 12V DC
• Gross weight49.5 g

Parametri

60x60x20mm
12VDC
uz ass
slīdgultnis
33.5dBA
38.19m3/st
4700apgr.
1.44W

Papildu dokumentācija
