Apraksts

• Manufacturer: Analog Devices Inc.
• Product Category: Instrumentation Amplifiers
• RoHS: Details
• Series: AD620
• Number of Channels: 1 Channel
• 3 dB Bandwidth: 1 MHz
• SR - Slew Rate: 1.2 V/us
• CMRR - Common Mode Rejection Ratio: 93 dB
• Ib - Input Bias Current: 500 pA
• Vos - Input Offset Voltage: 30 uV
• Supply Voltage - Max: 18 V
• Supply Voltage - Min: 2.3 V
• Operating Supply Current: 900 uA
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Mounting Style: SMD/SMT
• Package/Case: SOIC-8
• Packaging: Tube
• Amplifier Type: Instrumentation Amplifier
• Brand: Analog Devices
• Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
• Gain V/V: 1 V/V to 10000 V/V
• Height: 1.5 mm
• Length: 5 mm
• Maximum Dual Supply Voltage: +/- 18 V
• Maximum Input Resistance: 10 GOhms
• Minimum Dual Supply Voltage: +/- 2.3 V
• Operating Supply Voltage: 2.3 V to 18 V
• Pd - Power Dissipation: 650 mW
• Product: Instrumentation Amplifiers
• Product Type: Instrumentation Amplifiers
• PSRR - Power Supply Rejection Ratio: 140 dB
