Apraksts

• Manufacturer E-SWITCH
• Type of switch vandal resistant
• Number of positions 2
• Stable positions number 1
• Contacts configuration SPST-NO
• DC contacts rating @R(at resistive load) 2A / 36V DC
• IP rating IP65
• Switching method(the position in bracket indicates momentary position.) OFF-(ON)
• Leads screw terminals
• Electrical life 200000 cycles
• Max. contact resistance: 50mΩ
• Operating Force 4N
• Mechanical durability 1000000 cycles
• Button shape convex
• Mounting hole diameter Ø19mm
• Manufacturer series PV1
• Ring shape rounded
• Contact material silver
• Contact plating silver plated
• Mounting on panel
• Operating temperature -20...55°C
• Gross weight19.77 g

Parametri

SPST-NO
2A/36VDC
OFF-(ON)
Poga
Bez fiksācijas
M19
Bez apgaismojuma
