• Features:
• 1) high-accuracy voltage detection circuit;
• 2) terminal of the charger using high voltage device;
• 3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, load short circuit);
• 4) MOS transistor can control the battery charge and discharge;
• Parameter:
• Over charge voltage: 4.25±0.05V
• Over charge release voltage:4.23±0.05V
• Over discharge voltage:2.54±0.1V
• Maximal continuous charging current: 2A
• Maximal continuous Discharging current: 2A
• Over current protection: 3A
• Size: L40*W4*T3mm
