Apraksts

• Manufacturer: Texas Instruments
• Product Category: Counter Shift Registers
• RoHS: Details
• Counting Sequence: Serial/Parallel to Serial/Parallel
• Number of Circuits: 2
• Number of Bits: 8 bit
• Package/Case: PDIP-24
• Logic Family: 40
• Logic Type: CMOS
• Number of Input Lines: 3
• Output Type: 3-State
• Propagation Delay Time: 700 ns, 240 ns, 170 ns
• Supply Voltage - Max: 18 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Packaging: Tube
• Brand: Texas Instruments
• Function: 8 Stage Static
• Mounting Style: Through Hole
• Number of Output Lines: 3
• Operating Supply Voltage: 3 V to 18 V
• Product Type: Counter Shift Registers
• Series: CD4034B

Parametri

Papildu dokumentācija
