Apraksts

• Manufacturer NINIGI
• Type of switch rotary
• Number of positions 3
• Stable positions number 3-position
• DC contacts rating @R
• (at resistance load) 0.1A / 16V DC
• Poles number 2
• Indexed positions 30°
• Operating temperature -30...80°C
• Leads for PCB
• Switching method
• (item in brackets is instantaneous) MBB (shorting)
• Contact material brass
• Max. contact resistance: 100mΩ
• Body material PBT
• Mechanical durability 10000cycles
• Min. insulation resistance 100MΩ
• Shaft surface knurled
• Shaft diameter 6mm
• Shaft length 20mm
• Fastening thread M7x0,75
• Switching torque 2.9Ncm Additional information
• Gross weight: 6.133 g

Parametri

0.1A/16VDC
3
Galetes parslēdzejs
2
