Apraksts

• Manufacturer OMRON OCB
• Type of switch microswitch SNAP ACTION
• Contacts configuration SPST-NO
• DC contacts rating @R(at resistive load) 0.1A / 30V DC
• Max. contact resistance: 100mΩ
• Switching method(the position in bracket indicates momentary position.) OFF-(ON)
• Number of positions 2
• Stable positions number 1
• IP rating IP67
• Leads for soldering
• Body dimensions 13.3x5.3x9.3mm
• Mechanical durability 500000 cycles
• Operating temperature -40...85°C
• Operating Force 1.5N
• Electrical life 200000 cycles
• Contact plating gold-plated
• Terminal pitch 4.53mm
• Manufacturer series D2QW

Parametri

SPST-NO
0.1A/30VDC
OFF-(ON)
IP67
Bez sviras
13.3x5.3x9.3mm

Papildu dokumentācija
