Apraksts

• Manufacturer NINIGI
• Connector plug
• Type of connector wire-wire
• Kind of connector male/female
• Connector series NLS
• Contacts pitch 6.35mm
• Number of pins 6
• Type of pin configuration 2x3
• Mechanical mounting for cable
• Locking system latch
• Connector variant w/o contacts
• Flammability rating UL94V-2
• Connectors features designed for any type of contacts
• Rated voltage  600V
• Operating temperature -25...85°C
• Enclosure material polyamide
• Additional information
• Gross weight: 3.92 g
• Manufacturer part number: NLSW-2X3

Parametri

6.35mm
2x3
6
Taisns
Uz vadu
NLS
Spraudnis

Papildu dokumentācija
