Apraksts

• Manufacturer NINIGI
• Type of switch push-button
• Number of positions 2
• Contacts configuration SPST-NC
• AC contacts rating @R
• (at resistive load) 1A / 250V AC
• Actuator colour red
• Illumination none
• Leads for soldering
• Switching method
• (item in brackets is instantaneous) ON-(OFF)
• Operating temperature -25...70°C
• Mounting on panel
• Button shape prominent, round
• Mounting hole diameter Ø7mm
• Max. contact resistance: 20mΩ
• Electrical life 50000cycles
• Body dimensions Ø9.2x27.5mm
• Body material metal-plastic
• Height above panel 12mm
• Stable positions number 1 Additional information
• Gross weight: 3.42 g

Parametri

SPST-NC
1A/250VAC
ON-(OFF)
Poga
Bez fiksācijas
M7
Bez apgaismojuma
