Apraksts

• Manufacturer: STMicroelectronics
• Product Category: Audio Amplifiers
• RoHS: Details
• Series: TDA7297
• Product: Audio Amplifiers
• Class: Class-AB
• Output Power: 15 W
• Mounting Style: Through Hole
• Type: 2-Channel Stereo
• Package/Case: Multiwatt-15
• Audio - Load Impedance: 8 Ohms
• THD plus Noise: 0.1 %
• Supply Voltage - Max: 18 V
• Supply Voltage - Min: 6.5 V
• Minimum Operating Temperature: 0 C
• Maximum Operating Temperature: + 70 C
• Packaging: Tube
• Description/Function: Speaker
• Height: 10.7 mm
• Input Type: Single
• Length: 19.6 mm
• Output Current: 2 A
• Supply Type: Single
• Width: 5 mm
• Brand: STMicroelectronics
• Gain: 32 dB
• Number of Channels: 2 Channel
• Operating Supply Current: 2 A
• Operating Supply Voltage: 9 V, 12 V, 15 V
• Output Signal Type: Differential
• Pd - Power Dissipation: 33000 mW
• Product Type: Audio Amplifiers
• PSRR - Power Supply Rejection Ratio: 56 dB
• Factory Pack Quantity: 500
• Subcategory: Audio ICs
• Unit Weight: 7,257 g
