Apraksts

• Manufacturer SCI
• Type of switch ROCKER
• Contacts configuration  SPST
• Number of positions 2
• Switching method  OFF-ON
• (the position in bracket indicates momentary position.)
• AC contacts rating @R  3A / 250V AC
• (at resistive load)
• Key button colour white
• Illumination none
• Max. contact resistance: 50mΩ
• Body colour white
• Flammability rating UL94V-2
• Operating temperature -25...70°C
• Leads screwless clamps
• Button marking I-O
• Shape oval
• Body dimensions 60x30x19mm
• Test voltage 1.5kV
• Manufacturer series R13-901-AC
• Stable positions number 2
• Dimensions see
• Additional information
• Gross weight: 16.84 g
• Manufacturer part number: R13-901-WW

Parametri

SPST
3A/250VAC
OFF-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
1
Bez apgaismojuma

Papildu dokumentācija
