Apraksts

• Manufacturer SCI
• Switch type ROCKER
• Stable positions number 1-position
• Contacts configuration SPST
• Switching method OFF-(ON)
• DC contacts rating
• (at resistance load) 10 A / 28 VDC
• Key button colour red
• Sealing IP65
• Illumination LED 24V DC
• Max. contact resistance: 50mΩ
• Flammability rating UL94V-2
• Operating temperature -20...85°C
• Leads 4.8x0.8mm connectors
• Panel thickness max 2.5mm
• Mounting hole diameter Ø20.2mm
• Number of positions 2
• Button marking blank
• Backlight colour red
• Body material polyamide
• Body dimensions Ø19.5 x 14.5mm
• Test voltage 1.5kV

Parametri

SPST
OFF-(ON)
2
IP65
1
Taustiņslēdzis
Bez fiksācijas
1
LED24VDC
10A/28VDC

Papildu dokumentācija
