Tumblers, 3PST-NO, ON-OFF, 10A/250VAC, lodēšanai, 6.3x0.8mm, M12, 33.4x27.5x18.9mm, baķelits, SCI, ar fiksaciju
Tumblers, 3PST-NO, ON-OFF, 10A/250VAC, lodēšanai, 6.3x0.8mm, M12, 33.4x27.5x18.9mm, baķelits, SCI, ar fiksaciju
Tumblers, 3PST-NO, ON-OFF, 10A/250VAC, lodēšanai, 6.3x0.8mm, M12, 33.4x27.5x18.9mm, baķelits, SCI, ar fiksaciju Tumblers, 3PST-NO, ON-OFF, 10A/250VAC, lodēšanai, 6.3x0.8mm, M12, 33.4x27.5x18.9mm, baķelits, SCI, ar fiksaciju

* Produktu fotogrāfijas ir tikai noskatīšanai un var dažreiz atšķirties no priekšmeta reāla izskata. Bet galvenās īpašības ir vienādas.

Tumblers, 3PST-NO, ON-OFF, 10A/250VAC, lodēšanai, 6.3x0.8mm, M12, 33.4x27.5x18.9mm, baķelits, SCI, ar fiksaciju

Cena: 6.53 €
00021102
R13432A101
4
  • Apraksts

    • Manufacturer SCI
    • Type of switch toggle
    • Number of positions 2
    • Contacts configuration 3PST-NO
    • Switching method(the position in bracket indicates momentary position.) ON-OFF
    • AC contacts rating @R(at resistive load) 10A / 250V AC
    • Leads 6,3x0,8mm connectors
    • Terminals plating nickel
    • Operating temperature -25...70°C
    • Kind of toggle round
    • Mounting hole diameter Ø12mm
    • Knob height 16.5mm
    • Max. contact resistance: 50mΩ
    • Body dimensions 33.4x27.5x18.9mm
    • Actuator material metal
    • Panel thickness max. 5mm
    • Body material bakelite
    • Test voltage 1.5kV
    • Flammability rating UL94HB
    • Manufacturer series R13-432
    • Stable positions number 2

    Parametri

    3PST-NO
    10A/250VAC
    OFF-ON
    2
    IP00
    2
    Tumblers
    Ar fiksāciju
    M12
    3
    Bez apgaismojuma
