Apraksts

• Manufacturer IC SWITCHES
• Type of switch toggle
• Number of positions 3
• Contacts configuration DP3T
• Switching method(the position in bracket indicates momentary position.) (ON)-OFF-(ON)
• AC contacts rating @R(at resistive load) 5A / 125V AC
• DC contacts rating @R(at resistive load) 5A / 28V DC
• Leads for soldering
• Operating temperature -30...85°C
• Kind of toggle round
• Mounting hole diameter Ø6.35mm
• Knob height 10.34mm
• Max. contact resistance: 10mΩ
• Electrical life 50000 cycles
• Actuator material brass
• Contact plating silver plated
• Min. insulation resistance 1000MΩ
• Related items 1MD4T1B1M1QE, ICE1
• Contact material copper alloy
• Body material brass
• Lever plating chromium
• Stable positions number 1

Parametri

DP3T
2A/250VAC
5A/28VDC
(ON)-OFF-(ON)
3
IP00
1
Tumblers
M6
2
Bez apgaismojuma
Bez fiksācijas

Papildu dokumentācija
