Apraksts

• Specification
• Switch type toggle
• Stable positions number 1-position
• Contacts configuration SPST
• Switching method ON-(ON)
• AC contacts rating
• (at resistance load) 15 A / 250 VAC
• Leads screw
• Operating temperature -20...55°C
• Mounting hole diameter Ø;12.2mm
• Knob height 17.5mm
• Toggle type round
• Number of positions 2
• Electrical life 10000cycles
• Body dimensions 29.5 x 14 x 15mm
• Contact plating silver nickel alloy
• Associated items U851

Parametri

SPST
15A/250VAC
ON-(ON)
2
IP00
1
Tumblers
M12
1
Bez apgaismojuma
Bez fiksācijas
15A/12VDC

Papildu dokumentācija
